Page 295 - Rayconn Retail lighting Catalogue 2022
P. 295
FLOW.IT IP20 www.rayconn.net
Cut hole
111mm
DL32-L 28W
CRI Beam Angle Luminous CCT Part Number
>90 15° 2644 lm 4000K DL32-28W-940-15-L
2164 lm 3000K DL32-28W-930-15-L
2013 lm 2700K DL32-28W-927-15-L
24° 2644 lm 4000K DL32-28W-940-24-L
2158 lm 3000K DL32-28W-930-24-L
2007 lm 2700K DL32-28W-927-24-L
36° 2714 lm 4000K DL32-28W-940-36-L
2216 lm 3000K DL32-28W-930-36-L
2061 lm 2700K DL32-28W-927-36-L
sales@rayconn.net sales@rayconn.net
Input Voltage (v): 220-240V
Dimming: On/Off,TRIAC,1-10V,DALI 350
Light source:
COB LED
www.rayconn.net Tilting Angle (degree): 90 Packaging: 430x430x350mm, 18pcs/CTN FLOW.IT
50.000h（L80-B10, Ta25°C）
luminaire Lifetime:
Rotation Angle (degree):
355
IP Rating:
20
430
Working Temperature (°C):
-5 ~ +30
430
Storage Temperature (°C) :
-20 ~ +50
Material:
Aluminium
Weight:15KG
Fitting Colors:
9016 Sandy White / 9017 Sandy Black
281 282
