Page 215 - Rayconn Retail lighting Catalogue 2022

ALTRACK 60 55 IP20 60 55 IP20

600 600 www.rayconn.net
200 255 200 255

55 55
ALSP35 6W ALSP55 15W
CRI Beam Angle Luminous CCT Part Number CRI Beam Angle Luminous CCT Part Number
>90 16° 557 lm 4000K ALRP35S-02NC06G40-S >90 15° 1120 lm 4000K ALRP55S-02NC15G40-S
525 lm 3000K ALRP35S-02NC06G30-S 1057 lm 3000K ALRP55S-02NC15G30-S
488 lm 2700K ALRP35S-02NC06G27-S 983 lm 2700K ALRP55S-02NC15G27-S
22° 554 lm 4000K ALRP35S-02NC06G40-M 20° 1071 lm 4000K ALRP55S-02NC15G40-M
522 lm 3000K ALRP35S-02NC06G30-M 1010 lm 3000K ALRP55S-02NC15G30-M
486 lm 2700K ALRP35S-02NC06G27-M 940 lm 2700K ALRP55S-02NC15G27-M
34° 555 lm 4000K ALRP35S-02NC06G40-F 28° 1100 lm 4000K ALRP55S-02NC15G40-F
524 lm 3000K ALRP35S-02NC06G30-F 1038 lm 3000K ALRP55S-02NC15G30-F
487 lm 2700K ALRP35S-02NC06G27-F 965 lm 2700K ALRP55S-02NC15G27-F
50° 973 lm 4000K ALRP55S-02NC15G40-WF
918 lm 3000K ALRP55S-02NC15G30-WF
854 lm 2700K ALRP55S-02NC15G27-WF
sales@rayconn.net sales@rayconn.net

Input Voltage (v): 220-240VDC Input Voltage (v): 220-240VDC
Dimming: On/Off,1-10V,DALI 365 Dimming: On/Off,1-10V,DALI 420 365
Light source:
COB LED
Light source:
COB LED
www.rayconn.net Tilting Angle (degree): 90 Packaging: 520x420x365mm, 32pcs/CTN Tilting Angle (degree): N/A Packaging: 520x420x365mm, 32pcs/CTN ALTRACK
luminaire Lifetime:
50.000h(L80-B10, Ta25°C)
luminaire Lifetime:
50.000h(L80-B10, Ta25°C)
Rotation Angle (degree):
Rotation Angle (degree):
350
N/A
520
420
20
IP Rating:
IP Rating:
20
-5 ~ +30
Working Temperature (°C):
Working Temperature (°C):
-5 ~ +30
Weight:16KG
520
-20 ~+50
-20 ~+50
Storage Temperature (°C) :
Storage Temperature (°C) :
Weight:16KG
Aluminium
Material:
Material:
Aluminium
9016 Sandy White / 9017 Sandy Black
9016 Sandy White / 9017 Sandy Black
Fitting Colors:
Fitting Colors:
201 202
